EFDA Receiver Multimode Fiber Optic WDM Coupler With SC Connector

Wuhan Geehe Optical Communication Co.,ltd
Contact Now

EFDA Receiver Multimode Fiber Optic WDM Coupler With SC Connector

  • 1
  • 2
  • 3

Brand Name : Geehe

Model Number : GH-OS-WDM-007

Certification : ISO9001:2015,RoHS,Telcordia GR-1221

Place of Origin : Wuhan,China

MOQ : 100 pcs

Price : Negotiation

Payment Terms : T/T, L/C, Western Union.Cash,Ali Pay

Supply Ability : 800 pcs/ day

Delivery Time : With 7-9 days after confirmed the order

Packaging Details : Plastic box per pc with Pressure defense sponge, outer carton

Module Name : Optical WDM Coupler With SC Connector

Port Type : 1×48

Fiber Type : PM Panda fiber

Jacket : 250um or 900nm or others

Connectors : With LC upc connectors

Pigtail Length : 1M,1.5M or customized

Common Pass port : PM980 or PM1550

Option Channel : 4, 8 , 16, 18 channels

Operating Wavelength : 980~1620 nm

Package : Mini package, Module package, Frame package

Contact Now

SGS Approved EFDA Receiver Multimode Optical WDM Coupler With SC Connector


Basic Information:

Fan Out Fused Coupler is built by using fused biconical taper (FBT) technology. It can be used to split the input signal at various ratios with low insertion loss.

Fused WDM modules: Fused WDM used in optical fiber amplifiers, such as 980/1550nm, 1480/1550nm, 980/1060nm Fused WDM;

Fused WDM module used in bi-directional or CWDM optical communication systems, such as 1310/1550nm WDM Module.

The connectors are available:LC-UPC,LC-APC,LC-PC,SC-UPC,SC-APC,SC-PC,FC-UPC,FC-APC,FC-PC,ST-UPC etc.


FBT WDM Benefit&Features:

* High Channel Isolation

* High Uniformity and reliability

* Low insertion and return loss

* Exceptionally Stable and Reliable

* Rugged, environmentally stable package

* Customization Supported

Certification And Compliance:

* GR-1209-CORE Requirements for passive optic components

* GR-1221-CORE Reliability assurance requirements for passive optical components

* GR-326-CORE Requirements for single-mode optical connectors sand jumpers assemblies

* TIA-604 Fiber optic connector interpretability standard

* ROHS Directive on the restriction of hazardous substances

EFDA Receiver Multimode Fiber Optic WDM Coupler With SC Connector

WDM Applications:

* FTTX

* Passive Optical Networks (PON)

* Digital, hybrid video systems

* CATV links & Fiber sensors

* Long -haul telecommunication

* Access /PON distributions

* Datacenter

EFDA Receiver Multimode Fiber Optic WDM Coupler With SC Connector

Specifications& Technology Parameters:

Fiber Type(dB) Corning HI1060flex or OFS BF05635-02 SMF-28e
Operating Wavelength(nm) 980 & 1550 1060 & 1550 1310 & 1550 1480 & 1550
Operating Bandwidth(nm) ±10/20 ±15 ±15
Grade P A P A P A P A
Insertion Loss(dB) ≤0.15 ≤0.25 ≤0.30 ≤0.40 ≤0.2 ≤0.3 ≤0.3 ≤0.35
Isolation(dB) ≥20 ≥18 ≥20 ≥18 ≥25 ≥18 ≥25 ≥18
PDL(dB) ≤0.05 ≤0.1 ≤0.05 ≤0.1 ≤0.05 ≤0.1 ≤0.1 ≤0.1
Directivity(dB) ≥55
Operating Temperature(℃) -40 ~ +85


* The above specification is excluding the connector
* Other specification can be made on customer requires


Ordering Information:

WDM- N- XX- XX- X- XX- XX- X
95:980&1550nm 135:1310&1550nm 65:1060&1550nm 45:1480&1550nm 01: :SMF-28e
02: HI1060flex,
03: OFS BF05635-02
1:1m
X:customization
25:250μM Fiber
09:900μM loose Fiber 20: 2mm cable
30: 3mm cable
SC:SC/UPC
SA:SC/APC
......
00:No connector
A: A
B: B
C:C
Grade Operation Wavelength Fiber Type Fiber Length Pigtail Type Connect Type Dimension

Wuhan Geehe Comm Service:

-- Continuous improvement; accepting new challenges
-- Innovating new processes, and creating new products for the benefit of our customers

-- Free samples for testing

-- Factory inspection, also accept the third party inspect

-- Younger Team

-- 15 years stable suppliers, the delivery date can be guaranteed
